Description
High-Voltage Performance
Moving up to a 4S (14.8V) configuration provides a significant boost in motor RPM and efficiency compared to standard 3S packs. This RED High Quality battery ensures your propulsion system has the “punch” needed for vertical climbs and rapid acceleration. At RoboShop BD, we ensure these packs are built with low internal resistance (IR), which prevents overheating during intense 4-cell operation and keeps your flight stable from takeoff to landing.
Professional Grade Durability
The RED “High Quality” series utilizes advanced automated stacking technology to provide consistent capacity across all four cells. This leads to a longer cycle life and better balance over time. The battery is equipped with heavy-duty 14AWG silicone output leads to handle high current flow without melting, and a standard JST-XH balance connector for safe charging with any modern balance charger.
Key Features
-
True 35C Constant Discharge: Supports high-current demands for brushless motors without significant voltage sag.
-
14.8V 4-Cell Power: Increased voltage for high-speed performance and professional UAV applications.
-
Premium Cell Matching: Every pack is tested for balanced internal resistance and voltage.
-
Pre-Soldered XT60: Features a high-temp nylon XT60 plug for a secure, low-loss power connection.
-
Compact Footprint: High energy density provides 2200mAh of power in a size compatible with most battery trays.
-
Safe Storage: Wrapped in a durable, protective heat-shrink sleeve to resist field wear.
Technical Specifications
| Specification | Details |
| Brand | RED (High-Quality Series) |
| Capacity | 2200 mAh |
| Voltage | 14.8V (4S1P) |
| Discharge Rate | 35C (Continuous) |
| Max Burst Rate | 70C |
| Connector Type | XT60 |
| Balance Connector | JST-XH |
| Wire Gauge | 14AWG High-Flex Silicone |
| Dimensions (LWH) | ~106mm x 35mm x 32mm |
| Weight | ~235g |
